CheeTah

A hybrid pixel electron detector for TEM, available with a Timepix3 or a Medipix3 chip. With Timepix3 it runs event-based: every electron is recorded with its position and a nanosecond timestamp, without frames and with noise-free readout, so acquisition is up to 1000x faster with far smaller datasets. That serves 4D-STEM, ptychography, time-resolved EELS and ultrafast TEM at low dose. With Medipix3 it counts electrons in frames with a high dynamic range, which suits 3DED, serial ED, PED and other diffraction work, and frame-based 4D-STEM.

The Detectors Behind your discovery!

Designed for Precision, Performance, and Reliability

Timepix3 streams electrons instead of frames, so data volume scales with the dose and every electron keeps its nanosecond timestamp whatever the acquisition speed; time bins are chosen afterwards in software. That makes in situ and ultrafast experiments, and low-dose work on beam-sensitive materials, practical.

Medipix3 counts electrons per pixel over the exposure. The chip is radiation hard and has a high dynamic range, so the transmitted beam needs no beam stop and sits in the same frame as the weak reflections, counted without readout noise.

Key features

Performance Highlights & Applications

4D-STEM

High-speed diffraction mapping for strain, orientation, and electric-field analysis.

Ptychography

Phase reconstruction with efficient electron usage.

Low-Dose Imaging

Characterization of beam-sensitive materials such as 2D materials and soft matter.

In Situ TEM

Real-time monitoring during heating, biasing, or mechanical testing.

Ultrafast TEM (UTEM)

Pump and probe experiments with time-resolved electron detection.

Transient Dynamics

Observation of phase transitions and non-equilibrium processes.
