An event-driven ion and electron imaging detector for velocity-map imaging, mass spectrometry, and time-of-flight experiments. It captures particle arrival time, position, and intensity at once, with multi-hit capability and no dead time between hits.
The Detectors Behind your discovery!
Hyperion captures particle arrival time, position, and intensity at the same time, giving a complete view of velocity-map imaging, mass spectrometry, and time-of-flight measurements. Its multi-hit, dead-time-free operation suits experiments where many particles arrive in quick succession.
Two configurations are available. The Quad-Pico (512x512 pixels, 320 Mhits/s, 1.56 ns time bin) integrates 3 ps timestamping with PicoTDC for high-throughput, high-precision ion and electron imaging. The TPX4 version (512x448 pixels, up to 1.2 Ghits/s, 195 ps time bin) is a Timepix4-based detector for high-throughput direct electron imaging.
Key features
High-speed ion and electron imaging with precise event attribution.
Improved signal-to-noise and broader detection range for clearer mass spectra.
Timing analysis with simultaneous ToA/ToT and external TDC synchronisation.
Data-driven detection of particle position, timing, and intensity.
Detection of high-mass ions and biomolecules across a broad mass-to-charge range.
Clustering, time-walk correction, and HDF5 output for Python and other tools.
